Option Explicit

Call Worm()

Sub Worm()


 Dim aObjects : aObjects = Rhino.GetObjects(“Select Curves”, 4, True, False)
 ’Dim intSamples : intSamples = Rhino.GetInteger(“Number of Cross Sections”, 50, 5)

 Dim i
 Dim arrCrossSections()

 For i = 0 To UBound(aObjects)

  Dim crvObject : crvObject = aObjects(i)

  ’ define number of sections based on crv length
  Dim dblSegments : dblSegments = Rhino.DivideCurveLength ( aObjects(i), 1)
  Dim intSamples : intSamples = UBound(dblSegments)


  Dim crvDomain : crvDomain = Rhino.CurveDomain(crvObject)
  Dim t, n, l

  l = RN(51, 56)

  Dim CrossSectionPlane
  Dim crvCurvature, crvPoint, crvTangent, crvPerp, crvNormal

  n = -1

  For t = crvDomain(0) To crvDomain(1) + 1e-9 Step (crvDomain(1)-crvDomain(0))/intSamples

   Dim dblBendRadius : dblBendRadius = random(1,5)
   Dim dblPerpRadius : dblPerpRadius = random(1,5)

   n = n+1

   crvCurvature = Rhino.CurveCurvature(crvObject, t)

   If IsNull(crvCurvature) Then

    crvPoint = Rhino.EvaluateCurve(crvObject, t)
    crvTangent = Rhino.CurveTangent(crvObject, t)
    crvPerp = Array(0,0,1)
    crvNormal = Rhino.VectorCrossProduct(crvTangent, crvPerp)

   Else

    crvPoint = crvCurvature(0)
    crvTangent = crvCurvature(1)
    crvPerp = Rhino.VectorUnitize(crvCurvature(4))
    crvNormal = Rhino.VectorCrossProduct(crvTangent, crvPerp)

   End If


   CrossSectionPlane = Rhino.PlaneFromFrame(crvPoint, crvPerp, crvNormal)
   ReDim Preserve arrCrossSections(n)
   arrCrossSections(n) = Rhino.AddEllipse(CrossSectionPlane, dblBendRadius, dblPerpRadius)

  Next

  If n < 1 Then Exit Sub

  Call Rhino.AddLoftSrf(arrCrossSections)
  ’Call Rhino.DeleteObjects(arrCrossSections)

 Next

End Sub

Function random(intLow,intUp)

 Randomize

 random = (intUp-intLow) * Rnd() + intLow

End Function

Function RN(nMin, nMax)
 RN = Null
 If Not IsNumeric(nMin) Then Exit Function
 If Not IsNumeric(nMax) Then Exit Function
 If nMin >= nMax Then Exit Function
 Randomize
 RN = Int((nMax – nMin + 1) * Rnd + nMin)
End Function
