Option Explicit
Call Weld()

Sub Weld()

 Dim aSrfs : aSrfs = Rhino.GetObjects(“Select Surface”,

 Dim i,n
 Dim aPts()
 Dim udom, vdom, uparam, vparam, arrpt, udiv, vdiv

 udiv = 100
 vdiv = 50

 For i = 0 To UBound(aSrfs)

  n = 0
  Dim strsurface : strSurface = aSrfs(i)

  ReDim colec2d(udiv, vdiv)

  udom = Rhino.SurfaceDomain(strsurface,0)
  vdom = Rhino.SurfaceDomain(strsurface,1)

  Rhino.EnableRedraw False

  Do Until n = 1000

   uparam = udom(0) + rnd * (udom(1) – udom(0))
   vparam = vdom(0) + rnd * (vdom(1) – vdom(0))

   ReDim Preserve aPts(n)
   aPts(n) = Rhino.EvaluateSurface(strsurface, array(uparam, vparam))

   If n >= 1 Then
    Dim vDir : vDir = rhino.VectorCreate(aPts(n-1), aPts(n))
    vDir = rhino.VectorScale(rhino.VectorUnitize(vDir), 0.05)
    Dim aPtEnd : aPtEnd = rhino.PointAdd(aPts(n), vDir)
    Dim aParam : aParam = rhino.SurfaceClosestPoint(strSurface,aPtend)

    ’ curly
    ’Dim scrv : sCrv = Rhino.AddInterpCrvOnSrfUV (strSurface, array(array(uparam, vparam),aParam))
    ’ ribars
    Dim scrv : sCrv = Rhino.AddLine (aPts(n), rhino.EvaluateSurface(strSurface,aParam) )

    Call Rhino.ExtendCurveLength (sCrv, 0, 0, (RN(0.05, 0.2)))

   End If

   n = n + 1

  Loop

  Rhino.EnableRedraw True
 Next
End Sub
Function RN (nMin, nMax)
 RN = Null
 Randomize
 RN = (nMax – nMin) * Rnd + nMin
End Function
